AWTea, Part 2: Graphic Design is My Passion

Welcome to part 2 of me explaining my descent into madness! I’ve iterated on the graphics handling a few times now and… It’s still not quite what I’d like. I’ve over-engineered some aspects of it, and under-engineered others. We’ll get into that later though.

For this post, I’ve broken it down into essentially a timeline. Starting from just ‘getting it working’ into its current state.

Era 1: Canvas2D

If you’re at all familiar with both the java.awt.Graphics class and HTML5 CanvasRenderingContext2D you may see a similarity or two… Or three, or four. There’s a number of functions that map 1-1. See these two functionally the same code segments:

import java.awt.*;

public class RectExample extends Component{

    @Override
    public void paint(Graphics g) {
        // Rectangle insides
        g.setColor(Color.RED);
        g.fillRect(10, 100, 50, 200);

        // Rectangle border
        g.setColor(Color.BLUE);
        g.drawRect(10, 100, 50, 200);
    }
}

And JavaScript:

const canvas = document.getElementById("rect-canvas");
const ctx = canvas.getContext("2d");
// Rectangle insides
ctx.fillStyle = "red";
ctx.fillRect(10, 100, 50, 200);

// Rectangle border
ctx.strokeStyle = "blue";
ctx.strokeRect(10, 100, 50, 200);

That single paint() call is a good demo, but it’s not exactly a functioning application. A Component doesn’t paint itself onto the void. It needs to be sitting in a Frame, which needs to be visible, which needs an event loop telling it when it can repaint. On the desktop all that plumbing is handled by AWT’s internals talking to the native windowing system. In the browser it’s a bit more complex. The Frame has to be mapped onto a <canvas>, requestAnimationFrame() has to be used to drive repaints (more on this in a later post when we get into the EventQueue - for now pretend we are rendering inside its callback like in JS), and then a chain of calls translating “this component is dirty, repaint it” into “call this component’s paint(Graphics g) with a Graphics backed by the canvas 2D context.”

Once that chain existed, the Canvas2D mapping paid off fast. Very fast. It wasn’t just fillRect / drawRect - clipping regions mapped onto ctx.clip, affine transforms mapped onto ctx.setTransform() - heck, even drawImage() has a near equivalent in Canvas2D’s ctx.drawImage(). For a while adding support for a new Graphics method was less “design a rendering strategy” and more “look up the Canvas2D equivalent and wire it through”. An Example¹:

public abstract class Canvas2DGraphics extends Graphics {

    protected Canvas2DContext ctx;
    private Color color;

    public void setColor(Color c) {
        // color -> #RRGGBB style syntax
        String name = ColorUtils.translateColor(c);

        this.ctx.setFillStyle(name);
        this.ctx.setStrokeStyle(name);

        this.color = c;
    }

    public Color getColor() {
        return this.color;
    }
}

However these were relatively small, and easy enough to get working. This was the point where things started to feel finished. Rectangles were on screen, text was drawn, images were showing up, and some layouts even functioned. Applets that hadn’t run in a browser in over a decade were suddenly rendering pixel-for-pixel, more or less how they used to. It felt like the hard part was over.

It wasn’t.

Era 2: Fonts - And Why They Suck.
